TY CH530 Macroporous Aminophosphonic Chelating Resin

TY CH530 Macroporous Aminophosphonic Chelating Resin

Lanlang ® TY CH530 is a sort of chelate resin which has weakly acidic aminophosphonic (-CH2NHCH2PO3-) in the styrene and DVB copolymer with special macroporous structure. This product can fix and chelated one or several kinds certain cation in a great range even in the solution with high content.

product-716-286

Products Description
TY-CH530-

Macroporous aminophosphonic chelating resin



Lanlang® TY CH530 is a highly efficient and versatile chelate resin that is designed to remove a variety of cations from water solutions. This resin is based on a unique copolymer of styrene and divinylbenzene that is characterized by its strong and stable macroporous structure. The resin features weakly acidic aminophosphonic (-CH2NHCH2PO3-) functional groups that bind to a wide range of cations, even in highly concentrated solutions.

Used for brine softening for chlor alkali industry



Lanlang® TY CH530 is ideal for use in a wide range of applications, including water treatment, metal ion separation, and ion exchange. The resin is particularly effective at removing heavy metal ions from industrial wastewater, such as lead, copper, cadmium, and nickel. The resin can also be used for selective ion separation in various chemical and pharmaceutical processes.

2



Product details 2

Competitive Equivalents

  • Purolite S940
  • DowDowex XZ87480
  • Resin Tech SIR-500
  • Bayer Lewatit TP260
  • Amberlite IRC747
  • Duolite C467
  • Sybron
  • Mitsubishi Diaion
  • Jacobi Resinex  CH-12
  • Ion exchange India Indion BSR



Basic Features



Application:

Brine softening in the chlor alkali industry

Polymer matrix structure:

Macroporous polystyrene crosslinked with divinylbenzene

Appearance:

White, spherical beads

Functional Group:

Aminophosphonic acid

Ionic form as shipped:

Na+



Hydraulic Properties



product-623-391



product-640-402

PRESSURE LOSS



BACKWASH

The graph above shows the expected pressure loss of Lanlang TY CH530 per foot of bed depth as a function of flow rate at various temperatures.



The graph above shows the expansion characteristics of Lanlang TY CH530 as a function of flow rate at various temperatures.
